Old Blackmoon Trojan, NEW Monetization Approach

Last updated at Thu, 10 Aug 2023 21:06:28 GMT

Rapid7 is tracking a new, more sophisticated and staged campaign using the Blackmoon trojan, which appears to have originated in November 2022. The campaign is actively targeting various businesses primarily in the USA and Canada. However, it is not used to steal credentials, instead, it implements different evasion and persistence techniques to drop several unwanted programs and stay in victims’ environment for as long as possible.

Blackmoon, also known as KRBanker, is a banking trojan first spotted in late September 2015 when it was used to target banks of the Republic of Korea. Back in 2015, it employed a “pharming” technique to steal credentials from targeted victims. This technique involved redirecting traffic to a forged website when a user attempts to access one of the banking sites being targeted by the cyber criminals. The fake site masquerades as the original site and urges visitors to submit their information and credentials.

Stage 1 - Blackmoon

The Blackmoon trojan was named after a debug string “blackmoon,” that is present in its code:

Blackmoon drops a dll into C:\Windows\Logs folder named RunDllExe.dll and implements a Port Monitor persistence technique. Port Monitors are related to the Windows Print Spooler Service or spoolsv.exe. When adding a printer Port Monitor, a user (or the attacker in our case) has the ability to add an arbitrary dll that acts as the monitor. There are two ways to add a Port Monitor: via Windows Registry for persistence or via a AddMonitor API call for immediate dll execution.

Our sample implements both, it calls AddMonitor API to immediately execute RunDllExe.dll:

It also sets a driver value in HKLM\SYSTEM\CurrentControlSet\Control\Print\Monitors\RunDllExe registry key to the malicious dll path.

Next, the malware adds a shutdown system privilege to the Spooler service by adding SeShutdownPrivilege to the RequiredPrivileges value of HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\Spooler registry key.

The malware disables Windows Defender by setting HKLM\SOFTWARE\Policies\Microsoft\Windows Defender\DisableAntiSpyware value to “1”.

It also stops and disables “Lanman” service (the service that allows a computer to share files and printers with other devices on the network).

To block all incoming RPC and SMB communication the malware executes the set of following commands:

netsh ipsec static add policy name=Block
netsh ipsec static add filterlist name=Filter1
netsh ipsec static add filter filterlist=Filter1 srcaddr=any dstaddr=Me dstport=135 protocol=TCP
netsh ipsec static add filter filterlist=Filter1 srcaddr=any dstaddr=Me dstport=135 protocol=UDP
netsh ipsec static add filter filterlist=Filter1 srcaddr=any dstaddr=Me dstport=139 protocol=TCP
netsh ipsec static add filter filterlist=Filter1 srcaddr=any dstaddr=Me dstport=139 protocol=UDP
netsh ipsec static add filter filterlist=Filter1 srcaddr=any dstaddr=Me dstport=445 protocol=TCP
netsh ipsec static add filter filterlist=Filter1 srcaddr=any dstaddr=Me dstport=445 protocol=UDP
netsh ipsec static add filteraction name=FilteraAtion1 action=block
netsh ipsec static add rule name=Rule1 policy=Block filterlist=Filter1 filteraction=FilteraAtion1
netsh ipsec static set policy name=Block assign=y

The malware sets two additional values under HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\aspnet_staters: Work and Mining, both set to “1”.

Next, the malware checks if one of the following services exists on the victim’s computer:

• clr_optimization_v3.0.50727_32
• clr_optimization_v3.0.50727_64
• WinHelpsvcs
• Services
• Help Service
• KuGouMusic
• WinDefender
• Msubridge
• ChromeUpdater
• MicrosoftMysql
• MicrosoftMssql
• Conhost
• MicrosotMaims
• MicrosotMais

If the service is found, it will be disabled (by setting “Start” value under HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\servicename to “4”) or deleted by using the DeleteService API call.

The malware enumerates running processes by using a combination of CreateToolhelp32Snapshot and Process32First and Process32Next API calls to terminate the service’s process (if one is running).

Finally, a Powershell command is executed to delete the running process’ file and the malware exits.

Stage 2 - RunDllExe.dll - injector

RunDllExe.dll is executed by Spooler service and is responsible for injecting a next stage payload into the newly executed svchost.exe process. The malware implements Process Hollowing injection technique. The injected code is a C++ file downloader.

Stage 3 - File Downloader

The downloader first checks if ‘Work’ and ‘Mining’ values exist and are set under HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\aspnet_staters registry key, if the values do not exist, it will create them and set both to “1”.

This part of the attack flow checks if all the necessary downloaded files are present (by using PathFileExistsA API call) on the PC,  if not, the malware sleeps for two minutes before every download and then uses the URLDownloadToFileA API call to download the following files:

• C:\WINDOWS\Temp\MpMgSvc.dll
• C:\WINDOWS\Temp\Hooks.exe
• C:\WINDOWS\Temp\MpMgSvc.exe
• C:\Windows\Microsoft.NET\Framework\v3.0\WmiPrvSER.exe

After the download, all files except MpMgSvc.dll are executed:

Stage 4 - Hook.exe - dropper

Hook.exe drops an additional dll to the user’s roaming folder C:\Users\Username\AppData\Roaming\GraphicsPerfSvcs.dll and creates a new service named GraphicsPerfSvcs, which will be automatically executed at system startup. The service’s name is almost identical to the legitimate service named GraphicsPerfSvc, which belongs to the graphics performance monitor service. Naming services and files similarly to those that exist on the victim’s OS is an evasion technique widely used by threat actors.

The dropper then starts the created service. It creates and executes a .vbs, which is responsible for deleting Hook.exe and the .vbs itself:

Stage 4.1 - MpMgSvc.exe - spreader MpMgSvc.exe first creates a new \BaseNamedObjects\Brute_2022 mutex. As it is responsible for spreading the malware, it drops Doublepulsar-1.3.1.exe, Eternalblue-2.2.0.exe, Eternalromance-1.4.0.exe and all required file libraries into the C:\Windows\Temp folder.

Then, it scans the network for PC’s with open 3306, 445, 1433 ports. If any open ports are found, the spreader will attempt to install a backdoor by using EternalBlue and send shellcode to inject dll with Doublepulsar as implemented in the Eternal-Pulsar github project .

There are two dlls dropped, one for x64 architecture and the second one for x86. When injected by Doublepulsar, it will download the first stage Blackmoon malware and follow the same execution stages described in this analysis.

Stage 4.2 - WmiPrvSER.exe - XMRig miner

WmiPrvSER.exe is a classic XMRig Monero miner. Our sample is the XMRig version 6.18, and it creates a BaseNamedObjects\\Win__Host mutex on the victim’s host. You can find a full report on XMRig here.

Stage 5 - GraphicsPerfSvcs service - dropper

As mentioned in the previous stage, the GraphicsPerfSvcs service will be started automatically at system startup. Every time it runs, it will check if two of the following files exist:

• C:\Windows\TEMP\ctfmoon.exe
• C:\Windows\Microsoft.NET\traffmonetizer\Traffmonetizer.exe


If not found, it will drop both those files and all needed dlls for their execution.

The dropper also creates two new firewall rules that allow all outbound connections from dropped files by executing the following commands:

• netsh advfirewall firewall add rule name=ctfmoon dir=out program=C:\Windows\Microsoft.NET\ctfmoon.exe action=allow
• netsh advfirewall firewall add rule name=traffmonetizer dir=out program=C:\Windows\Microsoft.NET\traffmonetizer\traffmonetizer.exe action=allow


The service stays up and constantly attempts to read from the URL: hxxp://down.ftp21[.]cc/Update.txt. At the time of the analysis, this URL was down so we were not able to observe its content. However, following the service code, it seems to read the URL content and check if it contains one of the following commands:

[Delete File], [Kill Proccess], or [Delete Service], which will delete file, kill process or delete service accordingly.

Stage 6 - Ctfmoon.exe and Traffmonetizer.exe - Traffic Stealers

GraphicsPerfSvcs service executes two dropped files: Ctfmoon.exe and Traffmonetizer.exe, both appeared to be Potentially Unwanted Programs (PUP’s) in the form of traffic stealers. Both are using the “network bandwidth sharing” monetization scheme to make “passive income”.

Ctfmoon.exe is a cli version of the Iproyal Pawns application. It gets the user email address and password as execution parameters to associate the activity and collect the money to the passed account. GraphicsPerfSvcs executes the following command line to start Iproyal Pawns: ctfmoon.exe -email=usax138@protonmail.com -password=123456Aa. -device-name=Win32 -accept-tos

We can see that the user mentioned in our execution parameters already made $169:

The Traffmonetizer.exe is similar to Ctfmoon.exe, created by Traffmonetizer. It reads the user account data from a settings.json file dropped in users roaming directory. Our .json file contains the following content:

{"Token":"1gUgURMzQiuGFgttIdjeZBS0G6fqFlVvhCKlqzfHd3o=","StartWithWindows":false,"Accepting":true}.

Conclusion

The analysis in this blog reveals the efforts threat actors put into the attack flow, by using several evasion and persistence techniques as well as different approaches to make passive income using victims’ resources.

MITRE ATT&CK Techniques:

IOC’s

References

• https://posts.slayerlabs.com/monitor-persistence/
